Huawei NE20E CR2M16BASA02 Router Module – High-Performance IP/MPLS

Usage Area

The Huawei NetEngine NE20E-S CR2M16BASA02 is a universal service router deployed as an aggregation node in IP backbone networks and as a core node in data center networks. It is also suited for flexible deployment at the access and aggregation layers of IP/MPLS networks, providing a comprehensive networking solution for enterprise users with diverse service requirements.

Construction Features

• Chassis equipped with 2 MPU slots, 2 NSP slots, and 16 PIC slots for modular expansion.
• Includes 2 AC power supply units for redundant power delivery.
• Built with Huawei-designed NP chips featuring hardware-based forwarding and non-blocking switching architecture.
• Runs on the proprietary Huawei VRP operating system for network management.
• Supports high-density fixed ports and a variety of interface types for WAN service access and aggregation.
• Designed for interoperability with other NE series routers in a unified network environment.

Technical Parameters

• Switching capacity: Up to 15.88 Tbit/s
• Throughput: 360 Mbit/s
• MPU slots: 2
• NSP slots: 2
• PIC slots: 16
• Power supply: 2 AC units
• Supported interfaces: E1/CE1, POS, CPOS, GE, 10GE, and 40GE

Standards & Certification

The router complies with industry standards for IP/MPLS networking equipment, ensuring reliable operation in carrier-grade environments. It is certified for use in enterprise and service provider networks, meeting requirements for high-availability and performance in backbone and data center deployments.
