Huawei NetEngine NE08E NEDMHOST1300 Service Host Module

What It Is

The Huawei NetEngine NEDMHOST1300 is a mid-range service router from the NE08E series, designed for enterprise edge and service provider aggregation deployments. This model features an enhanced clock frequency, dual control boards, and redundant DC power supply for improved reliability and forwarding performance. It supports a forwarding capacity of 112 Gbit/s for IPv4/IPv6 traffic.

Technical Details

• Forwarding rate (IPv4/IPv6): 112 Gbit/s
• Forwarding rate (IMIX): 37,162 Mbit/s (NED2CXPB), 47,297 Mbit/s (NED2CXPE)
• Control plane: dual control boards for high availability
• Power supply: dual DC power inputs for redundancy
• Clock: enhanced clock frequency for precise synchronization
• Interface support: 10 GE, GE, FE, Smart E1/T1
• Additional interfaces: STM-1, GPON, xDSL, RS232, RS485, FXO, FSO, E&M, X.21/V.35/X.24

Configuration & Options

• Base chassis includes dual control boards and dual DC power modules.
• Optional interface modules: NED2CXPB and NED2CXPE for varying IMIX throughput profiles.
• Supported line cards for 10 GE, GE, and FE connectivity.
• Additional service modules for legacy TDM (E1/T1, STM-1) and serial (RS232/RS485, X.21/V.35) interfaces.
• Access interface options include GPON, xDSL, FXO, FSO, and E&M.

Operating Conditions

The Huawei NetEngine NEDMHOST1300 is intended for deployment in telecommunication rooms and data centers where redundant power and high availability are required. It operates in controlled indoor environments with standard enterprise temperature and humidity ranges. The router is suitable for aggregation points in service provider networks and large enterprise campus cores, handling mixed IP and legacy TDM traffic.
