Juniper QFX10002-60C 60-Port 100GbE Switch

Product Description

The Juniper QFX10002-60C is a high-performance spine switch for data center deployments, operating under Junos OS. Designed for enterprise and service provider networks, this 2U form-factor device delivers 60 ports of 100GbE (QSFP28) connectivity, offering a switching capacity of 5.76 Tbps and a forwarding performance of 2 billion packets per second (Bpps). It is a scalable solution for building high-speed data center cores and IP fabric architectures.

Technical Specifications

• Ports: 60 x 100GbE (QSFP28)
• Switching Capacity: 5.76 Tbps
• Forwarding Rate: 2 Bpps
• Form Factor: 2U
• Power Supply: 4 x 1600W AC
• Cooling: 3 fans
• Operating System: Junos OS
• Mounting: Standard 19-inch rack

Design Features

• High-density 100GbE QSFP28 ports for maximum fabric throughput.
• Redundant AC power architecture with four 1600W supplies.
• Front-to-back airflow supported by three hot-swappable fans.
• Compact 2U chassis optimized for space-constrained data center racks.
• Junos OS integration for consistent network management and automation.

Application Area

This switch is deployed as a spine device in data center IP fabric architectures, aggregating traffic from leaf switches at 100GbE speeds. It is suitable for building high-speed network cores in enterprise data centers and collocation facilities requiring dense 100GbE aggregation and low-latency forwarding. The QFX10002-60C supports scalable, flat network designs for cloud-scale workloads and virtualized environments.
