Huawei NetEngine5000E CR5P5KBASD64 Cluster Router

Usage Area

The Huawei NetEngine5000E CR5P5KBASD64 is a cluster router designed for deployment in large-scale data centers and core network nodes of telecom operators. It is intended for building high-capacity IP/MPLS backbone networks, supporting multi-chassis clustering for seamless network expansion. The system is suited for environments requiring ultra-high throughput, redundancy, and carrier-grade reliability. It enables service provider consolidation of core routing functions with advanced scalability up to 819 Tbit/s.

Construction Features

• Modular chassis design based on the NetEngine5000E-X16A platform, optimized for DC (data center) power input.
• Non-blocking switching fabric enables multi-chassis interconnection across up to 64 chassis.
• 16 line card slots per chassis, supporting flexible interface module configuration.
• High-density 100G base configuration, ready for 400G upgrade paths.
• Redundant architecture for control and forwarding planes, ensuring fault tolerance.
• Passive backplane and hot-swappable components for simplified maintenance.

Technical Parameters

• Product code: Huawei CR5P5KBASD64
• System capacity: 819 Tbit/s (64 chassis, 400G)
• Port throughput: 15 Tbit/s per single chassis (480G)
• Chassis slots: 16 slots per chassis
• Switching fabric: Non-blocking, multi-chassis supported
• Interface types: 100G base interfaces (per source configuration)
• Power supply: DC input (direct current)

Standards & Certification

The router complies with industry-standard IP/MPLS routing protocols and carrier-grade NEBS (Network Equipment Building System) requirements, as typical for Huawei NetEngine5000E series platforms. It supports multi-chassis clustering per standard MPLS and Segment Routing architectures, ensuring interoperability within multi-vendor networks. The equipment meets enterprise data center environmental and safety norms for continuous operation.
