Dell N1524P 24-Port Gigabit PoE+ Managed Switch

Usage Area

The Dell N1524P (MPN 677554) is a managed Layer 2 PoE+ switch deployed in growing GbE networks requiring high-density aggregation, predictable redundancy, and continuous readiness. It is suitable for edge and access layers in enterprise LANs, where it powers IP telephony, wireless access points, and surveillance devices. The unit supports stacking for scalable port capacity in medium-sized server rooms and distribution points. Its 10GbE uplinks provide backbone connectivity for bandwidth-intensive applications.

Construction Features

• 24x 10/100/1000 Base-TX RJ-45 ports with PoE+ support
• 4x fixed 10GbE SFP+ uplink ports for high-speed aggregation
• Stackable design (stacking cable not included) for scalability
• Airflow direction from ports to PSU for efficient thermal management
• Part of the Dell N1500 series with fixed-port architecture
• 3-year ProSupport Next Business Day (3YPSNBD) service coverage (210-AEVY)

Technical Parameters

• Line: N1500
• Switch type: Managed (Layer 2)
• Access technology: Ethernet
• Connector types: RJ-45, SFP+
• LAN ports: 24x 10/100/1000 Base-TX (1000 Mbit/s)
• SFP+ ports: 4x (10GbE)
• Ethernet protocols: IEEE 802.3ab, IEEE 802.3u
• IPv6 support: Yes

Standards & Certification

The switch complies with IEEE 802.3ab and IEEE 802.3u Ethernet standards, ensuring interoperability with standard network infrastructure. It supports IPv6 for modern addressing requirements. The unit meets industry norms for managed Layer 2 switching and PoE+ power delivery, aligning with enterprise deployment standards.
